Automatic high-precision laboratory press with 4 columns for silicone and organic rubber dies production equipped with plates heated by electric resistances. It is suitable for medium hardness compounds.
Charcateristics
- Sturdy steel structure processed by CNC machining centre
- Digital timer for vulcanising cycle
- No. 4 chrome columns
- Adjustable clamping force through digital pressure gauge
- Dual digital thermoregulator (with SCR output) for temperature setting
- Cylinder processed by CNC machining centre
- Chrome-plated and rectified steel plunging piston, Ø 110 mm
- Tempered-glass window to check the working area
- Led Strip for lighting of the working area
- Automatic-cycle starting button
- Discend button
- Emergency mushroom button
- Master switch
| TECHNICAL DATA | |
|---|---|
| Heating plates dimensions | 350 x 350 mm | 13.78 x 13.78″ |
| Opening between plates | 200 mm | 7.87″ |
| Operating pressure | 30 – 220 bar |
| Adjustable temperature | 20 – 200°C | 68 – 392°F |
| Maximum clamping force | 22 TON |
| Power | 3500 W |
| Voltage | 400V Three-phase (on request: 230V Three-phase) |
| Frequency | 50 / 60 Hz |
| Dimensions | 670 x 730 x 1170 mm | 26.38 x 28.74 x 46.06″ |
| Weight | 350 kg | 771.62 lbs |
| Noise output | < 70 dB |
